Model | DCP-8665L | DCP-8675L | DCP-8686L | DCP-8698L |
Screen Size | 65 Inch | 75 Inch | 86 Inch | 98 Inch |
Assembly Technology | Zero-bonding | Zero-bonding | Zero-bonding | Zero-bonding |
Backlight Type | DLED direct-lit | DLED direct-lit | DLED direct-lit | DLED direct-lit |
Display Type | 2D | 2D | 2D | 2D |
Pixel Pitch | 0.372×0.372 (H×V) [68PPI] | 0.42975×0.42975 mm [59PPI] | 0.4935×0.4935 mm (H×V) [51PPI] | 0.5622×0.5622 mm [45PPI] |
Active Display Size | 1428*803mm | 1650.24*928.26mm | 1895.04*1065.96mm | 2158.85*1214.35mm |
Screen Ratio | 16: 9 | 16: 9 | 16: 9 | 16: 9 |
Physical Resolution | 3840* 2160 | 3840* 2160 | 3840* 2160 | 3840* 2160 |
Brightness | 300-350cd(Center Brightness) | 350cd(Center Brightness) | 350cd(Center Brightness) | 350cd(Center Brightness) |
Contrast Ratio | 4000: 1 | 5000: 1 | 4000: 1 | 6000: 1 |
Color Gamut | 72% | 72% | 72% | 72% |
Display Color | 1.07B（8-bit+Hi-FRC） | 1.07B（8-bit+Hi-FRC） | 1.07B（8-bit+Hi-FRC） | 1.07B（8-bit+Hi-FRC） |
Viewing Angle | 178° | 178° | 178° | 178° |
Refresh Rate | 60Hz | 60Hz | 60Hz | 60Hz |
Response Time | 8ms | 8ms | 8ms | 8ms |
Speaker Power | 15W*2 8Ω | 15W*2 8Ω | 15W*2 8Ω | 15W*2 8Ω |
Touch Type | Infrared Touch | Infrared Touch | Infrared Touch | Infrared Touch |
Touch Points | Windows: 40 points / Android: 20 points | Windows: 40 points / Android: 20 points | Windows: 40 points / Android: 20 points | Windows: 40 points / Android: 20 points |
Driver Method | HID, driver-free | |||
Touch Surface Material | 4mm Tempered Glass, Hardness 7H | 4mm Tempered Glass, Hardness 7H | 4mm Tempered Glass, Hardness 7H | 4mm Tempered Glass, Hardness 7H |
Touch Recognition | Finger or Opaque Touch-Conductive Medium | Finger or Opaque Touch-Conductive Medium | Finger or Opaque Touch-Conductive Medium | Finger or Opaque Touch-Conductive Medium |
Touch Screen Resolution | 32767* 32767 | 32767* 32767 | 32767* 32767 | 32767* 32767 |
Touch System Communication Port | USB2.0 | |||
Detection & Certification | Built-in Software Auto-detection Function | Built-in Software Auto-detection Function | Built-in Software Auto-detection Function | Built-in Software Auto-detection Function |
Response Time | 8ms | |||
Numbers of Touches | Unlimited | |||
Scanning Rate | 100 Hz/s | 100 Hz/s | 100 Hz/s | 100 Hz/s |
Cursor Speed | 125 P/S | 125 P/S | 125 P/S | 125 P/S |
Touch Accuracy | ≦1mm | ≦1mm | ≦1mm | ≦1mm |
Installation & Maintenance | Rear/Side Serviceable | Rear/Side Serviceable | Rear/Side Serviceable | Rear/Side Serviceable |
Supported Touch OS | Windows XP / Windows 7 / Windows 10 / Linux / Android | |||
PC Type | Plug-in Intel Core Series Modular OPS Module | |||
PC Interface | 80pin OPS-C Standard | |||
Product Dimension | 1493×908×87.9mm | 1714.8×1032.5×88mm | 1961.2×1171.9×88mm | 2217.84×1326×95mm |
Dimensions of the Whole Machine (with Mounting Bracket) | 1493×908×117.5mm | 1714.8×1032.5×120mm | 1961.2×1171.9×120mm | 2217.84×1326×130mm |
Mounting Hole Pattern | 400×500mm | 400×600mm | 400×800mm | 400×1000mm |
Recommended In-wall Mount Dimensions | 1561×1024×118mm | 1792×1170×120mm | 2050×1337×120mm | 2328×1520×120mm |
Package Size | 1585×200×1030mm | 1820×230×1160mm | 2065×230×1300mm | 2401×320×1492mm |
Net Weight / Gross Weight | 41.5kg / 51.5kg | 50.4±1kg/63±1KG | 68.5±1kg/83.8±1KG | 97.5±1kg/128±2KG |
Installation Method | Wall Mount Bracket (Standard) | |||
Front I/O Ports | USB 3.0 ×1, USB 2.0 ×1, HDMI IN ×1, TOUCH ×1, Type-C ×1 | USB 3.0 ×1, USB 2.0 ×1, HDMI IN ×1, TOUCH ×1, Type-C ×1 | USB 3.0 ×1, USB 2.0 ×1, HDMI IN ×1, TOUCH ×1, Type-C ×1 | USB 3.0 ×1, USB 2.0 ×1, HDMI IN ×1, TOUCH ×1, Type-C ×1 |
Buttons Function | Power, Eye Protection, Settings, Volume +, Volume −, Aspect Ratio, Screen Recording | Power, Eye Protection, Settings, Volume +, Volume −, Aspect Ratio, Screen Recording | Power, Eye Protection, Settings, Volume +, Volume −, Aspect Ratio, Screen Recording | Power, Eye Protection, Settings, Volume +, Volume −, Aspect Ratio, Screen Recording |
Storage Temperature | -20-50℃, Storage Temperature 10%-50%RH | -20-50℃, Storage Temperature 10%-50%RH | -20-50℃, Storage Temperature 10%-50%RH | -20-50℃, Storage Temperature 10%-50%RH |
Working Environment | -20-40℃, Storage Temperature 10%-50%RH | |||
Service Life | ≥30,000 hours | ≥30,000 hours | ≥30,000 hours | ≥30,000 hours |
Working Voltage | 110-240V 50/60Hz | 110-240V 50/60Hz | 110-240V 50/60Hz | 110-240V 50/60Hz |
Power Consumption | Approx. 180 W | Approx. 320 W | Approx. 370 W | Approx. 370 W |
Motherboard Model | GK6780V1.G | GK6780V1.G | GK6780V1.G | GK6780V1.G |
Android Version | Android14 | |||
CPU | A55×8, 1.2 GHz, up to 1.5 GHz | A55×8, 1.2 GHz, up to 1.5 GHz | A55×8, 1.2 GHz, up to 1.5 GHz | A55×8, 1.2 GHz, up to 1.5 GHz |
GPU | G52×4 (4 Core) | G52×4 (4 Core) | G52×4 (4 Core) | G52×4 (4 Core) |
Memory | 4 GB+32 GB (Optional: 8 GB+128 GB) | 4 GB+32 GB (Optional: 8 GB+128 GB) | 4 GB+32 GB (Optional: 8 GB+128 GB) | 4 GB+32 GB (Optional: 8 GB+128 GB) |
Side Ports | RS232 ×1, PC TOUCH ×1, HDMI IN ×2, RJ45 IN ×1, USB 2.0 ×2, TF Card ×1 | |||
Right-side Ports | COAX ×1, MIC IN ×1, LINE OUT ×1, HDMI OUT ×1 | |||
WiFi or Bluetooth | Wi-Fi 5(2.4 GHz + 5 GHz) + Bluetooth 5.0 | |||
Supported Audio/Video Formats | 3GP, 3G2, AVI, FLV, F4V, OGG, MP4, MOV, TS, M2TS, M2T, MTS, TP, TRP, M2P, MKV, VOB, DAT, M4V, ASF, WEBM, 3GP, MP3, WAV, MPEG, PCM, MKA | |||
Supported Android Image Formats | JPEG (Hard Solution), PNG (Hard Solution), GIF, BMP | |||
Supported Video Codecs | H263, H264, H265, MPEG2, MPEG4, VC1, VP6, VP8, VP9, MJPEG, AVS, AVS+, AVS2 | |||
