4K UHD Resolution: 8.42M megapixel high quality SONY CMOS sensor. Resolution is up to 4K with frame rate up to 30fps.
Optical Zoom Lens: 12X optical zoom 80.5°wide-angle lens.
Leading Auto Focus Technology: Fast, accurate and stable auto focusing technology.
Low Noise and High SNR: Super high SNR image is achieved with low noise CMOS. Advanced 2D and 3D noise reduction technology further reduces the noise while ensuring high image clarity.
Various video output interfaces: support HDMI, USB3.0, LAN interface; support POE+ power supply, USB3.0 supports dual stream.
Multiple Audio/Video Compression Standards: Support YUY2, MJPEG, H.264, H.265, NV12 video encoding formats, MJPEG, H.264, H.265 support up to 3840×2160 resolution 30fps compression; support AAC audio compression .
Audio Input Interface: support AAC audio compression, AAC and MP3 support 16000, 32000, 44100, 48000 sampling frequency.
Built-in Gravity Sensor: Support PTZ auto-flip function and easy installation.
Multiple Network Protocol: Support ONVIF, GB/T28181, RTSP, RTMP,VISCA OVER IP,IP VISCA,RTMPS,SRT protocols; Support RTMP push mode, easy to be connected to streaming server (Wowza, FMS); Support RTP multicast mode.
Control Interface: RS232 input
Multiple Control Protocol: Support VISCA, PELCO-D, PELCO-P protocols; Support automatic identification protocols.
Quiet Pan / Tilt Movement: With high accuracy step driving motor, camera can pan / tilt extremely quiet and smooth.
Low-power sleep function: Support low-power sleep/wake-up, and the power consumption during sleep is less than 400mW.
Multiple Presets: Up to 255 presets (10 presets via remote control).
Auto Framing: Built-in high speed processor and face detection algorithm, automatically detect participants and provide ideal framing.
Intelligent voice positioning and tracking: Built-in 6 omnidirectional microphone arrays with intelligent sound source localization algorithm, capable of real-time speaker position tracking, with configurable voice tracking on/off function.
Multiple Application: Online-education, Lecture Capture, Webcasting, Video conferencing, Tele-medicine, Unified Communication, Emergency command and control systems, etc.
Model | D7139 |
Camera Parameter | |
Optical Zoom | 12X |
Sensor | 1/2.8 inch SONY CMOS sensor |
Effective Pixels | 8.42M megapixel 16:9 |
Frequency Response | 60Hz-18kHz |
Video Format | HDMI: 4KP30, 4KP25, 1080P30, 1080P25, 1080P29.97; USB3.0: Main stream: YUY2/NV12: 1920×1080/1280×720/1024×576/800×600/800×448/640×480/640×360/480×270/320×180@30/25/20/15/10/5fps; MJPG/H264: 1920×1080/1600×896/1280×720/1024×576/960×540/800×600/800×448/720×576/720×480/640×360/640×480/480×270/352×288/320×240@30/25/20/15/10/5fps; Secondary stream: YUY2/NV12: 1920×1080/1280×720/1024×576/800×600/800×448/640×360/640×480/480×270/320×180@30/25/20/15/10/5fps;MJPG/H264: 1920×1080/1600×896/1280×720/1024×576/960×540/800×600/800×448/720×576/720×480/640×360/640×480/480×270/352×288/320×240@30/25/20/15/10/5fps; |
Close-up Parameters | 12X |
Viewing Angle | Horizontal: 7.6°(N)~80.5°(W) |
Iris Value | F1.8 ~F3.6 |
Digital Zoom | 15X |
Minimum Illumination | 0.5Lux(F1.8, AGC ON) |
DNR | 2D&3D DNR |
White Balance | Auto / Manual/ One Push/ Specified Temperature |
Focus | Auto/Manual/One Push Focus |
Exposure Mode | Auto/Manual/Shutter priority/Aperture priority/brightness priority |
Aperture | F1.8 ~F11, CLOSE |
Shutter Speed | 1/25~1/20000 |
BLC | ON/OFF |
WDR | OFF/ 1~8 |
Video Adjustment | Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve |
SNR | >50dB |
Panoramic lens | Fixed |
Viewing Angle | 110.2°\101.8°\69.5°(D\H\V) |
Aperture | F2.0±5% |
Focal Length | F=1.89mm |
Interface Parameter | |
Video Interfaces | HDMI, LAN(Support POE+), USB3.0, LINE-IN, RS232-IN, DC12V Power Supply, Power Switch |
Video Output | HDMI, LAN, USB3.0 |
Video Compression Format | LAN: H.264, H.265 USB 3.0: MJPG, H.264, YUY2, NV12 |
Audio Input | Double track 3.5mm linear input; |
Audio Compression Format | AAC |
LAN Jack | 10M/100M adaptive Ethernet port, support POE+ power supply, support audio and video output |
Network Protocols | RTSP/RTMP,ONVIF,GBT28181, VISCA OVER IP, IP VISCA、RTMPS, SRT, Support remote upgrade, remote restart, remote reset |
Control Jacks | RS232-IN |
Serial Port Communication Protocols | VISCA/Pelco-D/Pelco-P; Support Baudrate: 115200/38400/9600/4800/2400 |
USB Communication Protocol | UVC (Video Communication Protocol) , UAC (Audio Communication Protocol) |
Power Supply | HEC3800 Outlet (DC12V) |
Power Adapter | AC110V~AC220V to DC12V/2A |
Input Voltage | DC12V±10% |
Input | ≤1.1A |
Consumption | ≤13W |
PTZ Parameter | |
Pan Move | -110°~+110° |
Tilt Move | -30°~+30° ° |
Pan Speed | 0.1°/s~100°/s |
Tilt Speed | 0.1°/s~70°/s |
Preset Speed | Pan: 78.8°/s, Tilt: 31.7°/s |
Preset Quantity | Up to 255 preset (10 via remote control) |
Other Parameter | |
Storage Temperature | -10℃~+60℃ |
Storage Humidity | 20%~95% |
Working Temperature | -10℃~+50℃ |
Working Humidity | 20%~80% |
Dimension | 220(L)mm*136mm(W)*159mm(H) |
Weight | About 1.7kg |
Environment | Indoors |
AI Function | |
Auto Framing | Built-in high speed processor and face detection algorithm, automatically detect participants and provide ideal framing. The farthest framing distance can reach 6~7 meters |
Intelligent voice positioning and tracking | Built-in 6 omnidirectional microphone arrays, intelligent sound source positioning algorithm, real-time positioning of the speaker's position, voice tracking can be set to on/off. The maximum pick-up distance can reach 6~7 meters |
